Pulse code generator

The HP 8110A is a versatile, high‑performance pulse generator designed for R&D, production test, and semiconductor characterization. Its robust build and precise controls make it a trusted workhorse in labs worldwide. Core Specifications Repetition Rate: 0.1 Hz to 150 MHz Pulse Modes: Normal, double‑pulse, burst, and gated operation Transition Times: Independently adjustable rise and fall times – from 1.5 ns (fast) up to 100 ms (slow) Output Amplitude: Up to 10 Vpp into 50 Ω, with adjustable DC offset Timing Resolution: High precision with low jitter for clean, reliable pulses Triggering: Internal, external, or manual trigger with variable delay Programmability & Connectivity GPIB / HP-IB interface for full remote control – ideal for automated test equipment (ATE) systems Front‑panel with backlit LCD and intuitive keypad for manual operation Reliability & Build Rugged, industrial‑grade construction – built to last for decades Over‑voltage and short‑circuit protection on outputs Compatible with 50 Ω and high‑impedance loads Applications Digital logic testing Clock and timing signal generation Device characterization (ICs, transistors, optoelectronics) Sensor and transducer excitation
