Key Highlights 30 MHz video bandwidth – Enables accurate measurement of wideband and pulsed signals Single‑shot real‑time capture at 100 Msamples/sec – Captures fast, transient signals with high fidelity Key measurements – Peak, average, peak‑to‑average ratio, rise time, fall time, and pulse width 22 predefined formats – Supports WiMAX, DME, HSDPA, and other industry‑standard signal formats One‑screen pulse measurement analysis – Auto Scale, Auto Gate, Rise/Fall Time, Duty Cycle, and more Internal zeroing and calibration – Performed while the sensor remains connected to the DUT, eliminating the need to disconnect Wide Frequency & Power Range Frequency range – 9 kHz to 110 GHz (with compatible sensors) Dynamic range – -70 to +44 dBm Peak frequency range – 50 MHz to 50 GHz Peak dynamic range – -35 to +20 dBm
